2012 | Apurva Kasture and Eleanor Pepper

Apurva and Eleanor were awarded a Team Gold CREST award for their project:

“CCA Treated Timber – A Risk Assessment”

Supervising teacher: Dr. Heather Meikle

Their Executive Summary states:

CCA treated timber” is timber that has been treated with CCA (a compound containing a mixture of copper, chromium and arsenic), which is a wood preservative used to prolong the life of the wood by preventing it from rotting. However, studies show that CCA leaches out of the wood over time, posing a risk to the environment due to the toxicity of copper, chromium and arsenic.

The aim of Apurva and Eleanor’s investigation was to carry out a risk assessment of CCA treated timber. This aim was achieved by completing the following two objectives:to determine the effect of leaching of CCA on two factors of soil health: the microbial activity and mineral nitrogen content of soil and to develop a new, less expensive method to quantify the leaching of CCA from CCA treated timber.

Apurva and Eleanor achieved their first objective by collecting soil samples around posts of two different ages (posts installed in 1991 and posts installed in 2003) at Te Mata Estate Winery in Hawke’s Bay. The samples were collected using a soil corer at three different distances (0, 10 and 20 cm) from the post, to a depth of 10 cm. Control samples were also collected from the soil area equidistant from the rows of grapevines (approximately a metre away from the posts).

 To determine the microbial activity of the soil, the dehydrogenase assay was conducted on the soil samples. The results of the assay showed that there was a significant difference in microbial activity between control samples and ‘other’ samples around the posts installed in 1991 but not the posts installed in 2003. This suggests that leaching does have an effect on the microbial activity of soil but only after a long period of time (in this case, at least 9 years).

To determine the mineral nitrogen content of the soil, Apurva and Eleanor conducted the mineral nitrogen extraction procedure on the soil samples. The results of the procedure showed that leaching may affect the mineral nitrogen content of soil (there is a tendency for a significant difference between the posts installed in 1991 and the posts installed in 2003).

Apurva and Eleanor‘s second objective was to develop a new, less expensive method to quantify the leaching of CCA from CCA treated timber. Current methods involve testing concentrations of copper, chromium and arsenic in surrounding soil and/or water, but these methods are expensive and complex to carry out. If a new, less expensive method was discovered, leaching prevention techniques could be developed more easily and could be also tested for their effectiveness.

Two new methods to quantify the leaching of CCA were investigated;measuring the pH/electrical conductivity of water in which CCA treated timber blocks were submerged and measuring the copper concentration of water in which CCA treated timber blocks were submerged using copper spectrophotometry.

For both methods, water surrounding untreated blocks was also tested, as a control. The blocks all had dimensions of 10 cm by 10 cm by 10 cm.

Apurva and Eleanor found that neither pH nor electrical conductivity can be used to quantify the leaching of CCA since there was no significant difference between water surrounding treated blocks and water surrounding untreated blocks. However, using copper spectrophotometry to measure the copper in water proved to be very successful and the copper concentration of the water surrounding the treated blocks averaged 4.68 mg/L after two months.
